Mermi yörüngesi üzerindeki doğrusal ve doğrusal olmayan etkili faktörlerin sayısal analizi

Yıl 2025, Cilt: 12 Sayı: 23, 18 - 38

Mohammad Zia Zahedi , Mohammad Ali Sultani

Öz

Robotik sistemler kullanarak mermileri yakalamak, robotik araştırmalarda önemli zorluklar ortaya çıkarmaktadır. Mermi yörüngesini anlamak ve hareketini etkileyen temel faktörleri belirlemek, bu alandaki temel görevlerdir. Bu çalışma, bir mermi hareketini etkileyen faktörleri kapsamlı bir şekilde analiz etmeyi amaçlamaktadır ve özellikle ping pong topunun yörüngesine odaklanmaktadır. Yerçekimi, kaldırma kuvveti, santrifüj kuvveti gibi doğrusal faktörler ve hava direnci, Coriolis kuvveti gibi doğrusal olmayan faktörler incelenmektedir. Ping pong topunun hareket denklemleri, MATLAB programlaması kullanılarak sayısal ve analitik yöntemlerle çözülmektedir. Çalışma, bu önemli faktörlerin topun hareketi ve yörüngesi üzerindeki etkisini yüzdelik olarak belirlemektedir. Her bir faktörün katkısını anlayarak, mermi davranışıyla ilgili daha doğru ve kapsamlı bir anlayış elde edilebilir. Mermi ile hedefin çarpışma noktasını belirlemek için, yörünge eğrisinin üzerine oturan bir yaklaşık bir parabolik eğri denklemi elde edilir. Bu denklem, hedefle kesin çarpışma noktasının tahmininde değerli bir içgörü sağlar. Önerilen yöntem, analitik ve sayısal hesaplamalardan elde edilen sonuçların karşılaştırılması ve detaylı analizi yoluyla doğrulanmıştır. Bu araştırmanın bulguları, görüntü tabanlı gözetim sistemleri, spor video görüntülerinin analizi, insan faaliyetlerinin izlenmesi ve insan-makine etkileşimini geliştirmek gibi çeşitli alanlarda geniş uygulamalara sahiptir. Mermi hareketini etkileyen tüm önemli faktörleri dikkate alarak ve inceleyerek, bu araştırma, mermilerin doğru ve verimli bir şekilde yakalanması için değerli içgörüler ve araçlar sunarak robotik araştırmaların ilerlemesine katkıda bulunmaktadır.

Anahtar Kelimeler

Doğrusal olmayan denklemler projektil hareketinin dinamikleri hava direnci kaldırma kuvveti sayısal yöntem
